Italian Aqua pump, 3 HP

Product specifications

1. Clear polycarbonate enanti-oxidation pre-filter to ensure continuous visibility over time.
2. Nylon filter. The impeller is in Technopolymer reinforced with glass fibres, developed to ensure complete coverage and isolation of the motor shaft from the pumped liquid. Diffuser in reinforced technopolymer. Mechanical seal in Carbon/Alumina/NBR/AISI 316. O-ring pump body in NBR, bolts and ring nuts in AISI 304 steel. Butterfly inlet and drain plugs that do not require the use of tools for removal and repositioning.
3. Degree of protection of motor and terminal block: IP 55. Insulation class: F. Standard voltages: Single-phase 220/240 V - 50 Hz. Three phase 230/400V - 50Hz. Operating range: up to 42 m3/h with head up to 22 m.
4. Pumped liquid: clean or slightly dirty water with suspended solids and long fibers; Particularly aggressive water with high chlorine/bromine ratios and PHMB (polyhexamethylene biguanide) or water treated by the chlorine electrolysis process.
5. Liquid temperature range: up to 60°C. Maximum ambient temperature: +50°C. Maximum operating pressure: 2.5 bar. Installation: fixed or portable in horizontal position.
